Specifications

Basic Information

Case size (L× W× H)

56.7 × 52.7 × 14.8 mm

Weight

88 g

Case and bezel material

Resin (Bio-based) / Stainless steel

Band

Bio-based resin band

Construction

Shock Resistant

Mud Resistant

Carbon Core Guard structure

Water resistance

200-meter water resistance

Time adjustment

Radio-controlled Watch; Multi band 6

Power supply and battery life

Tough Solar (Solar powered)

Sensor feature

Digital compass

Measures and displays direction as one of 16 points

Measuring range: 0 to 359°

Measuring unit: 1°

60 seconds continuous measurement

Graphic direction pointer

Bidirectional calibration

Magnetic declination correction

Bearing memory

Altimeter

Measuring range: -700 to 10,000 m (-2,300 to 32,800 ft.)

Measuring unit: 1 m (5 ft.)

Manual memory measurements (up to 30 records, each including altitude, date, time)

Auto log data (High/low altitudes, auto cumulative ascent and descent)

Trek log data (up to 14 records of high/low altitudes, auto cumulative ascent and descent of particular treks)

Others: Relative altitude readings (-3,000 to 3,000 m),

Selectable measurement interval: 5 seconds or 2 minutes

*1 second for first 3 minutes only

*Changeover between meters (m) and feet (ft)

Barometer

Display range: 260 to 1,100 hPa (7.65 to 32.45 inHg)

Display unit: 1 hPa (0.05 inHg)

Atmospheric pressure tendency graph (Past 42 hours of readings)

Atmospheric pressure differential graphic

Barometric pressure tendency information alarm (beep and arrow indicate significant changes in pressure)

*Changeover between hPa and inHg

Thermometer

Display range: -10 to 60℃ (14 to 140℉)

Display unit: 0.1℃ (0.2℉)

*Changeover between Celsius (℃) and Fahrenheit (℉)

Exterior

Glass

Mineral Glass

Surface treatment

Black ion plated bezel

Compatible band size

145 to 215 mm

Watch Features

World time

World time

31 time zones (48 cities + coordinated universal time), daylight saving on/off

Sunrise/sunset display

Sunrise, sunset time display

Sunrise time and sunset time for specific date

Stopwatch

1/10-second stopwatch

Measuring capacity: 999:59'59.9''

Measuring modes: Elapsed time, split time, 1st-2nd place times

Timer

Countdown timer

Measuring unit: 1 second

Countdown start time setting range: 24 hours

Countdown start time setting range: 1 minute to 24 hours (1- minute increments and 1-hour increments)

Alarm/hourly time signal

5 daily alarms (with 1 snooze alarm)

Hourly time signal

Light

LED backlight (Super Illuminator)

Full auto LED light, selectable illumination duration (1.5 seconds or 3 seconds), afterglow

Light color

LED:White

Calendar

Full auto-calendar (to year 2099)

Mute feature

Button operation tone on/off

Energy saving feature

Power Saving (Turns off the display when the watch is left in the dark)

Battery display/alert

Battery level indicator

Run time

Approx. battery operating time:

6 months on rechargeable battery (operation period with normal use without exposure to light after full charge)

26 months on rechargeable battery (operation period when stored in total darkness with the power save function on after full charge)

Accuracy

Accuracy: ±15 seconds per month (with no signal calibration)

Other features

12/24-hour format

Regular timekeeping:

Hour, minute, second, pm, month, date, day

Duplex LC display

Time adjustment details

Time calibration signal reception

Auto receive up to six* times a day (remaining auto receives canceled as soon as one is successful)

*5 times a day for the Chinese calibration signal

Manual receive

The latest signal reception results

Time Calibration Signals

Station name: DCF77 (Mainflingen, Germany)

Frequency: 77.5 kHz

Station name: MSF (Anthorn, England)

Frequency: 60.0 kHz

Station name: WWVB (Fort Collins, United States)

Frequency: 60.0 kHz

Station name: JJY (Fukushima, Fukuoka/Saga, Japan)

Frequency: 40.0 kHz (Fukushima) / 60.0 kHz (Fukuoka/Saga)

Station name: BPC (Shangqiu City, Henan Province, China)

Frequency: 68.5 kHz

Special colours evoking the look of the team’s rally car

The watch features a black and red colour scheme inspired by the Land Cruiser 300 GR Sport, the car raced by TLC in the Dakar Rally. IP is applied to the metal bezel as part of the overall black look, which is set off with red accents, including the red line decorating the button at 3 o’clock and side surfaces. The design evokes the toughness of a racing machine capable of delivering in harsh conditions across an approximately 10,000-km course.

Band design capturing the desert setting of the rally

Designed to capture the feel of racing through desert sands, the sand-colored band is printed with a black splatter pattern that evokes tracks left by speeding racers. IP in the same brown hue is also applied to the guard for the front button.

Official logo to commemorate a special collaboration

As a symbolic design for the official watch actually used in the rally, the band and case back are adorned with the Team Land Cruiser logo. Even more, when the LED backlight is illuminated, a TLC graphic appears on the LCD.

Attention to materials

Key resin components used in the case and band are made with bio-based resin. Produced using renewable organic resources, this material is expected to help reduce environmental impact. Recycled materials are used for the special packaging, as well.

Tough design to stand up to demanding use

The solid, rugged exterior design features a multi-component structure and independent front button. Incorporating cut glass with a special glass adhesion method and a Carbon Core Guard structure, the watch has a smaller, slimmer form that delivers everything you want — durability, operability, and a highly comfortable fit.

Duplex LCD: Delivering improved compass readability

The top layer of the LCD provides a graphical compass display, while the bottom layer provides large measurement and time displays. The LCD has also been made slimmer to minimise bulk, even while being dual-layer.

Mud-resistant structure to withstand use in the harshest conditions

The front button and three direct sensor buttons feature large, easy-to-operate forms designed to keep mud and water out. The buttons are protected by cylindrical stainless-steel parts, and the button shafts are equipped with gasket fittings to prevent contamination with mud and dust.

Multiband 6 radio control and solar power for accurate timekeeping

Super Illuminator (high-brightness full-auto LED backlight) for maintaining watch readability in the dark
